Zemismart ZM25TQ

ModelZM25TQ
VendorZemismart
DescriptionTubular motor
Exposescover (state, position), upper_stroke_limit, middle_stroke_limit, lower_stroke_limit
PictureZemismart ZM25TQ

Options

How to use device type specific configuration

  • time_start: Reply to Tuya-specific time synchronization requests: "1970" - Reply with seconds since 1970/01/01 (recommended, should stop the device from asking), "2000" - Reply with seconds since 2000/01/01 (use if the weekday is wrong with 1970), "off" - Don't reply (use if replying causes too much traffic). Default for this device: "off". The value must be one of 1970, 2000, off

  • invert_cover: Inverts the cover position and state, false: open=100,close=0, true: open=0,close=100 (default false). The value must be true or false

Exposes

Cover

The current state of this cover is in the published state under the state property (value is OPEN or CLOSE). To control this cover publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"state": "OPEN"}, {"state": "CLOSE"}, {"state": "STOP"}. It's not possible to read (/get) this value. To change the position publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"position": VALUE} where VALUE is a number between 0 and 100.

Upper stroke limit (enum)

Set / Reset the upper stroke limit. Value can be found in the published state on the upper_stroke_limit property. It's not possible to read (/get) this value. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"upper_stroke_limit": NEW_VALUE}. The possible values are: SET, RESET.

Middle stroke limit (enum)

Set / Reset the middle stroke limit. Value can be found in the published state on the middle_stroke_limit property. It's not possible to read (/get) this value. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"middle_stroke_limit": NEW_VALUE}. The possible values are: SET, RESET.

Lower stroke limit (enum)

Set / Reset the lower stroke limit. Value can be found in the published state on the lower_stroke_limit property. It's not possible to read (/get) this value. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"lower_stroke_limit": NEW_VALUE}. The possible values are: SET, RESET.
