AVATTO ZBTS60-03
| Model | ZBTS60-03 |
| Vendor | AVATTO |
| Description | 3 gang switch module with backlight |
| Exposes | switch (state), countdown, backlight_mode, indicator_mode, inching_control_set |
| Picture |  |
Options
How to use device type specific configuration
state_action: State actions will also be published as 'action' when true (default false). The value must betrueorfalse
Exposes
Switch (l1 endpoint)
The current state of this switch is in the published state under the state_l1 property (value is ON or OFF). To control this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"state_l1": "ON"}, {"state_l1": "OFF"} or {"state_l1": "TOGGLE"}. To read the current state of this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"state_l1": ""}.
Switch (l2 endpoint)
The current state of this switch is in the published state under the state_l2 property (value is ON or OFF). To control this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"state_l2": "ON"}, {"state_l2": "OFF"} or {"state_l2": "TOGGLE"}. To read the current state of this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"state_l2": ""}.
Switch (l3 endpoint)
The current state of this switch is in the published state under the state_l3 property (value is ON or OFF). To control this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"state_l3": "ON"}, {"state_l3": "OFF"} or {"state_l3": "TOGGLE"}. To read the current state of this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"state_l3": ""}.
Countdown (numeric)
Countdown to turn device off after a certain time. Value can be found in the published state on the countdown property. It's not possible to read (/get) this value. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"countdown": NEW_VALUE}. The minimal value is 0 and the maximum value is 43200. The unit of this value is s.
Power outage memory (enum)
Recover state after power outage. Value can be found in the published state on the power_outage_memory property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"power_outage_memory": ""}. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"power_outage_memory": NEW_VALUE}. The possible values are: on, off, restore.
Switch type (enum)
Type of the switch. Value can be found in the published state on the switch_type property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"switch_type": ""}. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"switch_type": NEW_VALUE}. The possible values are: toggle, state, momentary.
Backlight mode (binary)
Mode of the backlight. Value can be found in the published state on the backlight_mode property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"backlight_mode": ""}. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"backlight_mode": NEW_VALUE}. If value equals ON backlight mode is ON, if OFF OFF.
Inching control set (composite)
Device Inching function Settings. The device will automatically turn off after each turn on for a specified period of time.. Can be set by publishing to zigbee2mqtt/FRIENDLY_NAME/set with payload {"inching_control_set": {"inching_control_1": VALUE, "inching_time_1": VALUE, "inching_control_2": VALUE, "inching_time_2": VALUE, "inching_control_3": VALUE, "inching_time_3": VALUE}}
inching_control(binary): Enable/disable inching function for endpoint 1. allowed values:ENABLEorDISABLEinching_time(numeric): Delay time for executing a inching action for endpoint 1. min value is 1, max value is 65535, unit is secondsinching_control(binary): Enable/disable inching function for endpoint 2. allowed values:ENABLEorDISABLEinching_time(numeric): Delay time for executing a inching action for endpoint 2. min value is 1, max value is 65535, unit is secondsinching_control(binary): Enable/disable inching function for endpoint 3. allowed values:ENABLEorDISABLEinching_time(numeric): Delay time for executing a inching action for endpoint 3. min value is 1, max value is 65535, unit is seconds
