SONOFF MINI-ZBRBS

Model	MINI-ZBRBS
Vendor	SONOFF
Description	Zigbee smart roller shutter switch
Exposes	cover (state, position), motor_travel_calibration_action, motor_travel_calibration_status, motor_run_status, external_trigger_mode

Notes

• Pairing the device is done by pressing the back button of the device for around 5 seconds.
• Automatic calibration can be triggered via Zigbee2MQTT by setting motor_travel_calibration_action to start_automatic. Alternatively, it can be initiated physically by holding the device button for around 10 seconds until the LED enters breathing mode; the device will then drive the motor through the full stroke automatically.
• Manual calibration via Zigbee2MQTT:
  1. Set motor_travel_calibration_action to start_manual to begin.
  2. Move the cover to the fully open position, then set motor_travel_calibration_action to manual_2_fully_opened. The device will automatically start moving the cover toward the closed position.
  3. Once the cover has reached the fully closed (end) position, set motor_travel_calibration_action to manual_3_fully_closed. Calibration is now complete.
• To reset the calibration, set motor_travel_calibration_action to clear.
• The current calibration status can be read from motor_travel_calibration_status (Uncalibrated or Calibrated).
• Percentage-based position control (position) requires a completed calibration.

OTA updates

This device supports OTA updates, for more information see OTA updates.

Options

How to use device type specific configuration

• invert_cover: Inverts the cover position, false: open=100,close=0, true: open=0,close=100 (default false). The value must be true or false

• cover_position_tilt_disable_report: Do not publish set cover target position as a normal 'position' value (default false). The value must be true or false

Exposes

Cover

The current state of this cover is in the published state under the state property (value is OPEN or CLOSE). To control this cover publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"state": "OPEN"}, {"state": "CLOSE"}, {"state": "STOP"}. It's not possible to read (/get) this value. To change the position publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"position": VALUE} where VALUE is a number between 0 and 100.

Motor travel calibration action (enum)

Calibrates the motor stroke, or clears the current one.. Value can be found in the published state on the motor_travel_calibration_action property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"motor_travel_calibration_action": ""}. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"motor_travel_calibration_action": NEW_VALUE}. The possible values are: start_automatic, start_manual, clear, manual_2_fully_opened, manual_3_fully_closed.

Motor travel calibration status (enum)

The calibration status of the curtain motor's stroke.. Value can be found in the published state on the motor_travel_calibration_status property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"motor_travel_calibration_status": ""}. It's not possible to write (/set) this value. The possible values are: Uncalibrated, Calibrated.

Motor run status (enum)

The motor's current operating status, such as forward rotation, reverse rotation, and stop.. Value can be found in the published state on the motor_run_status property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"motor_run_status": ""}. It's not possible to write (/set) this value. The possible values are: Stop, Forward, Reverse.

External trigger mode (enum)

External trigger mode, which can be one of edge, pulse, following(off), following(on). The appropriate triggering mode can be selected according to the type of external switch to achieve a better use experience.. Value can be found in the published state on the external_trigger_mode property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"external_trigger_mode": ""}. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"external_trigger_mode": NEW_VALUE}. The possible values are: edge, pulse, following(off), following(on).
