IKEA E1746 #

Model E1746
Vendor IKEA
Description TRADFRI signal repeater
Exposes linkquality
Picture IKEA E1746

Notes #

Pairing #

Push the reset button of the device with a paperclip for 5 seconds. While pairing the LED is flashing/dimming slowly. Once the pairing is finished, the LED stays on.

Tips for monitoring this device #

The device send a payload exactly 1 hours after the first pairing and a payload each exactly 4 hours after. You can track the activity of this device by observing the lastseen value. If now () - lastseen > 4 h, then your equipment has lost its connectivity

OTA updates #

This device supports OTA updates, for more information see OTA updates.

Exposes #

Linkquality (numeric) #

Link quality (signal strength). Value can be found in the published state on the linkquality property. It’s not possible to read (/get) or write (/set) this value. The minimal value is 0 and the maximum value is 255. The unit of this value is lqi.

Manual Home Assistant configuration #

Although Home Assistant integration through MQTT discovery is preferred, manual integration is possible with the following configuration:

sensor:
  - platform: "mqtt"
    state_topic: "zigbee2mqtt/<FRIENDLY_NAME>"
    availability_topic: "zigbee2mqtt/bridge/state"
    value_template: "{{ value_json.linkquality }}"
    unit_of_measurement: "lqi"
    enabled_by_default: false
    icon: "mdi:signal"
    state_class: "measurement"

sensor:
  - platform: "mqtt"
    state_topic: "zigbee2mqtt/<FRIENDLY_NAME>"
    availability_topic: "zigbee2mqtt/bridge/state"
    icon: "mdi:update"
    value_template: "{{ value_json['update']['state'] }}"
    enabled_by_default: false

binary_sensor:
  - platform: "mqtt"
    state_topic: "zigbee2mqtt/<FRIENDLY_NAME>"
    availability_topic: "zigbee2mqtt/bridge/state"
    payload_on: true
    payload_off: false
    value_template: "{{ value_json.update_available}}"
    enabled_by_default: false
