Aqara ZNMHLDJ01LM


Model	ZNMHLDJ01LM
Vendor	Aqara
Description	Smart vertical blinds motor H1
Exposes	identify, cover (state, position, tilt), manual_open_close, status, last_manual_operation, traverse_time, calibration_status, calibrated, identify_beep

Options

How to use device type specific configuration

identify_timeout: Sets the duration of the identification procedure in seconds (i.e., how long the device would flash).The value ranges from 1 to 30 seconds (default: 3). The value must be a number with a minimum value of 1 and with a maximum value of 30
invert_cover: Inverts the reported cover position and the state derived from it, false: open=100,close=0, true: open=0,close=100 (default false). The value must be true or false
cover_position_tilt_disable_report: Do not publish set cover target position as a normal 'position' value (default false). The value must be true or false

Initiate device identification. Value will not be published in the state. It's not possible to read (/get) this value. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"identify": NEW_VALUE}. The possible values are: identify.

Cover

The current state of this cover is in the published state under the state property (value is OPEN or CLOSE). To control this cover publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"state": "OPEN"}, {"state": "CLOSE"}, {"state": "STOP"}. It's not possible to read (/get) this value. To change the position publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"position": VALUE} where VALUE is a number between 0 and 100. To change the tilt publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"tilt": VALUE} where VALUE is a number between 0 and 100.

Manual open close (binary)

Gently pull to open/close the curtain automatically. Value can be found in the published state on the manual_open_close property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"manual_open_close": ""}. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"manual_open_close": NEW_VALUE}. If value equals ON manual open close is ON, if OFF OFF.

Status (enum)

Current status of the curtain (Opening, Closing, Stopped, Blocked). Value can be found in the published state on the status property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"status": ""}. It's not possible to write (/set) this value. The possible values are: closing, opening, stopped, blocked.

Last manual operation (enum)

Last triggered manual operation. Value can be found in the published state on the last_manual_operation property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"last_manual_operation": ""}. It's not possible to write (/set) this value. The possible values are: open, close, stop.

Traverse time (numeric)

Time in seconds to get from one end to another. Value can be found in the published state on the traverse_time property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"traverse_time": ""}. It's not possible to write (/set) this value. The unit of this value is sec.

Calibration status (enum)

Calibration status of the curtain (Not calibrated, Half calibrated, Fully calibrated). Value can be found in the published state on the calibration_status property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"calibration_status": ""}. It's not possible to write (/set) this value. The possible values are: not_calibrated, half_calibrated, fully_calibrated.

Calibrated (binary)

Indicates if this device is calibrated. Value can be found in the published state on the calibrated property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"calibrated": ""}. It's not possible to write (/set) this value. If value equals true calibrated is ON, if false OFF.

Identify beep (enum)

Device will beep for chosen time duration. Value can be found in the published state on the identify_beep property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"identify_beep": ""}. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"identify_beep": NEW_VALUE}. The possible values are: off, short, long.
