Orztech _TZE200_pcg0rykt

Model	_TZE200_pcg0rykt
Vendor	Orztech
Description	3 gang touch wall switch
Exposes	switch (state)

Exposes

Switch (t1 endpoint)

The current state of this switch is in the published state under the state_t1 property (value is ON or OFF). To control this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"state_t1": "ON"}, {"state_t1": "OFF"} or {"state_t1": "TOGGLE"}. To read the current state of this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"state_t1": ""}.

Switch (t2 endpoint)

The current state of this switch is in the published state under the state_t2 property (value is ON or OFF). To control this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"state_t2": "ON"}, {"state_t2": "OFF"} or {"state_t2": "TOGGLE"}. To read the current state of this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"state_t2": ""}.

Switch (t3 endpoint)

The current state of this switch is in the published state under the state_t3 property (value is ON or OFF). To control this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"state_t3": "ON"}, {"state_t3": "OFF"} or {"state_t3": "TOGGLE"}. To read the current state of this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"state_t3": ""}.

Switch (c1 endpoint)

The current state of this switch is in the published state under the state_c1 property (value is ON or OFF). To control this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"state_c1": "ON"}, {"state_c1": "OFF"} or {"state_c1": "TOGGLE"}. To read the current state of this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"state_c1": ""}.

Switch (c2 endpoint)

The current state of this switch is in the published state under the state_c2 property (value is ON or OFF). To control this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"state_c2": "ON"}, {"state_c2": "OFF"} or {"state_c2": "TOGGLE"}. To read the current state of this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"state_c2": ""}.

Switch (c3 endpoint)

The current state of this switch is in the published state under the state_c3 property (value is ON or OFF). To control this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"state_c3": "ON"}, {"state_c3": "OFF"} or {"state_c3": "TOGGLE"}. To read the current state of this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"state_c3": ""}.

Switch (c4 endpoint)

The current state of this switch is in the published state under the state_c4 property (value is ON or OFF). To control this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"state_c4": "ON"}, {"state_c4": "OFF"} or {"state_c4": "TOGGLE"}. To read the current state of this switch publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"state_c4": ""}.
