Immax 07504L

Model07504L
VendorImmax
DescriptionNeo outdoor smart siren (IP65)
Exposesbattery, battery_low, voltage, alarm, volume, duration, light, power_source
PictureImmax 07504L

Exposes

Battery (numeric)

Remaining battery in %, can take up to 24 hours before reported. Value can be found in the published state on the battery property. It's not possible to read (/get) or write (/set) this value. The minimal value is 0 and the maximum value is 100. The unit of this value is %.

Battery low (binary)

Indicates if the battery of this device is almost empty. Value can be found in the published state on the battery_low property. It's not possible to read (/get) or write (/set) this value. If value equals true battery low is ON, if false OFF.

Voltage (numeric)

Voltage of the battery in millivolts. Value can be found in the published state on the voltage property. It's not possible to read (/get) or write (/set) this value. The unit of this value is mV.

Alarm (binary)

Value can be found in the published state on the alarm property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"alarm": ""}. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"alarm": NEW_VALUE}. If value equals true alarm is ON, if false OFF.

Volume (numeric)

Volume of siren. Value can be found in the published state on the volume property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"volume": ""}. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"volume": NEW_VALUE}. The minimal value is 0 and the maximum value is 50. Besides the numeric values the following values are accepted: off, low, medium, high.

Duration (numeric)

Duration of alarm. Value can be found in the published state on the duration property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"duration": ""}. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"duration": NEW_VALUE}. The minimal value is 0 and the maximum value is 3600. The unit of this value is s.

Light (numeric)

Strobe light level. Value can be found in the published state on the light property. To read (/get) the value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/get with payload {"light": ""}. To write (/set) a value publish a message to topic zigbee2mqtt/FRIENDLY_NAME/set with payload {"light": NEW_VALUE}. The minimal value is 0 and the maximum value is 100. Besides the numeric values the following values are accepted: off, low, medium, high.

Power source (enum)

The current power source. Value can be found in the published state on the power_source property. It's not possible to read (/get) or write (/set) this value. The possible values are: mains, battery.

Help to make the docu better and edit this page on Github ✌
Last Updated:: 5/7/25, 7:30 PM
