Aqara WXKG04LM

ModelWXKG04LM
VendorAqara
DescriptionWireless remote switch T1 (double rocker)
Exposesbattery, voltage, action
PictureAqara WXKG04LM

OTA updates

This device supports OTA updates, for more information see OTA updates.

Exposes

Battery (numeric)

Remaining battery in %, can take up to 24 hours before reported. Value can be found in the published state on the battery property. It's not possible to read (/get) or write (/set) this value. The minimal value is 0 and the maximum value is 100. The unit of this value is %.

Voltage (numeric)

Voltage of the battery in millivolts. Value can be found in the published state on the voltage property. It's not possible to read (/get) or write (/set) this value. The unit of this value is mV.

Action (enum)

Triggered action (e.g. a button click). Value can be found in the published state on the action property. It's not possible to read (/get) or write (/set) this value. The possible values are: button_1_hold, button_1_release, button_1_single, button_1_double, button_1_triple, button_2_hold, button_2_release, button_2_single, button_2_double, button_2_triple, button_3_hold, button_3_release, button_3_single, button_3_double, button_3_triple.

Help to make the docu better and edit this page on Github ✌
Last Updated:: 5/7/25, 7:30 PM
